JAD Line Heat Exchangers
JAD shell & coil heat exchangers are distinctly characterized by their angular connections, and by the concentric layers of helically corrugated tubes within the shell. This unique design optimizes the performance and heat transfer efficiency of the units.
This line of heat exchangers is primarily designed for vertical installations and combined with their compact size, the JAD heat exchangers can be installed in virtually any application where space is a constraint.
Shell & Coil Models are available in:
- Smooth or corrugated tubes
- H-Type: Straight, 90° angle connections
Standard Materials
- Stainless Steel 316L
- Complete welded structure
Maximum Working Pressure
- Up to 300 PSI (2.07 MPa)
Maximum Working Temperature
- Up to 422°F (216°C)
Larger models of the shell and coil heat exchangers are designed to different parameters. Call AIC for details.
The JAD angular connections accommodate smooth, gradual flow entrances and exits from the unit, reducing any sharp corners that can result in flow separation and where dirt buildup can occur.
The vertical configuration has the intrinsic advantage of being used as a condenser or evaporator for supporting changes of fluid phases within the unit (e.g. steam to liquid). The small footprint results in less installation space requirements and low installation costs. It is ideal for applications with space constraints.
Advantages
- Compact with high heat transfer
- Stainless steel 316L
- Complete welded structure
- Enhanced turbulent flow
- Enhanced structural support
- Enhanced heat transfer coefficient
- Cost efficiency
- Vertical mounting
- Quick and easy installation
Applications
- Central heating systems
- Solar & geothermal heating
- Hydronic heating
- Steam sub-cooling
- Clean steam generators
- Thermosiphon reboiler
- Boiler sample coolers
- Vent Condensers
Features
- Compact footprint
- Angular connections
- Concentric layered coils
- Helically corrugated tubes
- Small to large applications
- H-Type for straight connections
- Standard class flange or NPT connections
- Easy to install in series or parallel
The product information and literature on this website are intended as a guideline for general purposes only. Models, dimensions, and operational parameters are subject to change at AIC's discretion. Contact AIC directly for updated design specifications.
JAD-Line Technical Product Specifications
