C-Line Titanium Pool Heaters

Swimming Pool Heat Exchangers

AIC introduces the all-new C-line heat exchangers designed for swimming pool applications. With a titanium coil and carefully chosen thermoplastic materials, the C-line guarantees outstanding resistance to corrosion, making it perfect for all kinds of pools.

Specifications Brochure Manual
Titanium Pool Heat Exchangers

Available in three power outputs, C-line heat exchangers are designed to perform in variety of swimming pool applications.

Contact Us
Features

Applications

  • Polls, spas , hot tubs
  • Applications with high chlorinated/saltwater concentrations
  • Removable tube bundle
  • Mounting brackets
  • Optional temperature sensors

Standard Materials

  • Titanium Coil
  • Plastic shell

Maximum Working Pressure

  • 70psi (5 bar) in Tube and Shell side

Maximum Working Temperature

  • 210F ( 99C) Tube side ( heating water)
  • 120F (50C) Shell side (pool water)

Sample Installation Diagram

  1. Boiler
  2. Heat Exchanger
  3. Swimming Pool
  4. Pumps
  5. Filtration
  6. Chlorine Feeder
  7. Circulation Pump
  8. Flow Control Valve
  9. Gate Valve
  10. Check Valve
  11. Thermometer
  12. Safety Relief Valve

The product information and literature on this website are intended as a guideline for general purposes only. Models, dimensions, and operational parameters are subject to change at AIC's discretion. Contact AIC directly for updated design specifications.

C-Line Product Specifications

C-150 C-250 C-350
kw kBTU/h kw kBTU/h kw kBTU/h
Nomial Capacity 44 150 78 265 100 340
l/min USGPM/h l/min USGPM/h l/min USGPM/h
Heating Water Flow 53 14 58 15 61 16
l/min USGPM/h l/min USGPM/h l/min USGPM/h
Pool Water Flow 300 77 300 77 300 77
Nomial Values are based on 60°C (250°F) temperature difference between incoming and heated water. For general reference only. Please consult our office for product selection verification
Dimensions
mm in mm in mm in
L 525 20.6 770 30.3 945 37.2
A 362 14.2 607 23.9 782 30.8
B 81 3.2 81 3.2 81 3.2
C 205 8.8 205 8.0 205 8.0
∅D 110 4.3 110 4.3 110 4.3
F - 1.5 - 1.5 - 1.5
G - 1 - 1 - 1
Pool Capacity*
USGAL m3 USGAL m3 USGAL m3
13000 50 22500 85 32000 120
*Heat Echanger Selection. For general reference only. Please consult out office for product selection verification. Based on 180°F (82.4°C) supply water and specified nominal flows

N1: Heating Fluid IN
N2: Heating Fluid OUT
N3: Cold Fluid OUT
N4: Cold Fluid IN
